Clear

Model: Billi Sparkling

Instantly at your fingertips
Boiling, Chilled & Sparkling water all dispense from the same tap

Safety first
Hot water safety lock and the Splash Free technology secure safe boiling water delivery. The inbuilt leakage detection system will automatically shut off the water inlet once leakage occurs.

Ice Bank cooling technology
Providing high capacity of chilled and sparkling water

Australian designed and manufactured.

Model: Quadra Sparkling 460

Dimensions:
(D)420x(W)255x(H)410 mm – Chilled & Sparkling unit
(D)465x(W)180x(H)340 mm – Boiling unit

Max.Boiling water delivery cups per hour:
up to 165 cups*(170ml/cup)

Max.Chilled & Sparkling water cups delivery per hour:
200 cups(170ml/cup)

Initial cup delivery and suggested no. of persons:
Up to 60

Cooling Technology
Air-cooled(Ventilation space required)

Filtration
NSF/ANSI 42 & 53 certified 2-stage filtration

Voltage / Frequency:
AC 220/240V

Wattage
2150W – Boiling unit
400W – Chilled & Sparkling unit

Total current draw amps
13AMPx2

Temperature:
(Cold) 5°C – 10°C
(Hot) 80°C – 99°C

*Based on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Usage patterns and draw-off methods can impact recovery.

Model: Quadra Sparkling 4100

Dimensions:
(D)420x(W)255x(H)410 mm – Chilled & Sparkling unit
(D)465x(W)180x(H)340 mm – Boiling unit

Max. Boiling water delivery cups per hour:
up to 220 cups* (170ml/cup)

Max. Chilled & Sparkling water cups delivery per hour:
200 cups(170ml/cup)

Initial cup delivery and suggested no. of persons:
Up to 100

Cooling Technology
Air-cooled(Ventilation space required)

Filtration
NSF/ANSI 42 & 53 certified 2-stage filtration

Voltage / Frequency:
AC 220/240V

Wattage
3300W – Boiling unit
400W – Chilled & Sparkling unit

Total current draw amps
1 * 13AMP & 1 * 20AMP

Temperature:
(Cold) 5°C – 10°C
(Hot) 80°C – 99°C

*Based on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Usage patterns and draw-off methods can impact recovery.

Description

Model: Quadra Sparkling 460

Dimensions:
(D)420x(W)255x(H)410 mm – Chilled & Sparkling unit
(D)465x(W)180x(H)340 mm – Boiling unit

Max.Boiling water delivery cups per hour:
up to 165 cups*(170ml/cup)

Max.Chilled & Sparkling water cups delivery per hour:
200 cups(170ml/cup)

Initial cup delivery and suggested no. of persons:
Up to 60

Cooling Technology
Air-cooled(Ventilation space required)

Filtration
NSF/ANSI 42 & 53 certified 2-stage filtration

Voltage / Frequency:
AC 220/240V

Wattage
2150W – Boiling unit
400W – Chilled & Sparkling unit

Total current draw amps
13AMPx2

Temperature:
(Cold) 5°C – 10°C
(Hot) 80°C – 99°C

*Based on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Usage patterns and draw-off methods can impact recovery.

Model: Quadra Sparkling 4100

Dimensions:
(D)420x(W)255x(H)410 mm – Chilled & Sparkling unit
(D)465x(W)180x(H)340 mm – Boiling unit

Max. Boiling water delivery cups per hour:
up to 220 cups* (170ml/cup)

Max. Chilled & Sparkling water cups delivery per hour:
200 cups(170ml/cup)

Initial cup delivery and suggested no. of persons:
Up to 100

Cooling Technology
Air-cooled(Ventilation space required)

Filtration
NSF/ANSI 42 & 53 certified 2-stage filtration

Voltage / Frequency:
AC 220/240V

Wattage
3300W – Boiling unit
400W – Chilled & Sparkling unit

Total current draw amps
1 * 13AMP & 1 * 20AMP

Temperature:
(Cold) 5°C – 10°C
(Hot) 80°C – 99°C

*Based on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Usage patterns and draw-off methods can impact recovery.
