Billi Sparkling Hospitality

Model: Quadra Sparkling 460

Dimensions:
(D)420x(W)255x(H)410 mm – Chilled & Sparkling unit
(D)465x(W)180x(H)340 mm – Boiling unit

Max.Boiling water delivery cups per hour:
up to 165 cups*(170ml/cup)

Max.Chilled & Sparkling water cups delivery per hour:
200 cups(170ml/cup)

Initial cup delivery and suggested no. of persons:
Up to 60

Cooling Technology
Air-cooled(Ventilation space required)

Filtration
NSF/ANSI 42 & 53 certified 2-stage filtration

Voltage / Frequency:
AC 220/240V

Wattage
2150W – Boiling unit
400W – Chilled & Sparkling unit

Total current draw amps
13AMPx2

Temperature:
(Cold) 5°C – 10°C
(Hot) 80°C – 99°C

*Based on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Usage patterns and draw-off methods can impact recovery.

Model: Quadra Sparkling 4100

Dimensions:
(D)420x(W)255x(H)410 mm – Chilled & Sparkling unit
(D)465x(W)180x(H)340 mm – Boiling unit

Max. Boiling water delivery cups per hour:
up to 220 cups* (170ml/cup)

Max. Chilled & Sparkling water cups delivery per hour:
200 cups(170ml/cup)

Initial cup delivery and suggested no. of persons:
Up to 100

Cooling Technology
Air-cooled(Ventilation space required)

Filtration
NSF/ANSI 42 & 53 certified 2-stage filtration

Voltage / Frequency:
AC 220/240V

Wattage
3300W – Boiling unit
400W – Chilled & Sparkling unit

Total current draw amps
1 * 13AMP & 1 * 20AMP

Temperature:
(Cold) 5°C – 10°C
(Hot) 80°C – 99°C

*Based on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Usage patterns and draw-off methods can impact recovery.
